Emissions Inspections
Date	Result	Mileage	Cost	RPM	MPH	Max HC	Meas HC	Max CO	Meas CO	Max NO	Meas NO	Meas CO2	Meas O2
5/2/2003	Passed	60,406	$48.20	1,465	15	105	11	0.60	0.01	992	4	15.30	0.00
5/2/2003	Passed	60,406	$48.20	1,489	25	93	5	1.03	0.00	852	19	15.30	0.00
4/18/2005	Passed	80,709	$48.20	1,547	15	100	2	0.56	0.02	975	22	14.10	0.10
4/18/2005	Passed	80,709	$48.20	1,563	25	89	0	0.99	0.05	835	4	14.10	0.00
4/3/2007	Passed	103,921	$58.00	1,536	15	100	10	0.56	0.04	975	76	14.86	0.42
4/3/2007	Passed	103,921	$58.00	1,519	25	89	5	0.99	0.00	835	6	14.70	0.32
4/23/2009	Passed	131,396	$58.00	1,553	15	100	22	0.56	0.03	975	115	14.97	0.00
4/23/2009	Passed	131,396	$58.00	1,531	25	89	6	0.99	0.00	835	16	14.80	0.00
5/19/2011	Passed	140,170	$58.00	1,698	15	100	21	0.56	0.02	975	147	14.89	0.00
5/19/2011	Passed	140,170	$58.00	1,694	25	89	7	0.99	0.00	835	46	14.90	0.00
5/10/2013	Passed	155,989	$58.00	1,477	15	100	49	0.56	0.20	975	11	14.40	0.05
5/10/2013	Passed	155,989	$58.00	1,474	25	89	39	0.99	0.28	835	18	14.31	0.05
4/17/2015	Passed	162,337	$68.00	1,736	15	100	44	0.56	0.15	975	247	14.80	0.00
4/17/2015	Passed	162,337	$68.00	1,667	25	89	22	0.99	0.04	835	54	14.40	0.50
3/18/2017	Failed*	171,598	$58.00	1,704	15	100	53	0.56	0.13	975	305	14.47	0.06
3/18/2017	Failed*	171,598	$58.00	1,718	25	89	17	0.99	0.01	835	231	14.63	0.00
3/18/2017	Passed	171,622	FREE	1,711	15	100	50	0.56	0.24	975	385	14.47	0.13
3/18/2017	Passed	171,622	FREE	1,667	25	89	20	0.99	0.01	835	169	14.60	0.01

* 3/18/2017 Failure caused by readiness monitors not being set because I had removed the battery. I drove the truck 24 miles and then retested the same day.

The CO and O2 vertical bars use the right-side Y axis.

The CO and O2 vertical bars use the right-side Y axis.


   Last update: Dec 7th, 2019
